from 3.350,00 € excl. VAT
Find your dealer Lupo

Lupo

Lupo

The recumbent bike of the Lupo model series is a complete system that is operated manually without a wheelchair or, as an optional extra, also electrically. It offers many advantages, because in addition to the adaptability of the seat, it can also be dismantled into two parts and transported in a space-saving manner.

With the Lupo, muscle training and the promotion of coordination between arms and legs is possible in the sporting sense. The robust steel frame in conjunction with the sophisticated aluminum milled parts, which holds the assemblies together, also allows intensive off-road use.

The Lupo can be equipped with a powerful Lipo drive system as the Lupo Smart. This turns the purely manual recumbent bike into a hybrid one. The backrest as well as the headrest can be readjusted without tools. This can make it much easier to get on and off the bike. It also makes it easier to use a sliding board.

Special feature

Handbike as sports and leisure equipment

Handbikes have a significant benefit for their riders. Due to the various movements that occur while riding, the muscles can be built up and physical coordination trained.

Illustration can deviate.

Dismountable for transport

The Lupo can be dismantled into two parts by removing the four screws on the aluminium milled body of the handlebar. This is particularly useful for transport.

Product images

+
+
+
+
+
+
+
+
+
+
+
+
+

Basic equipment

The specifications depend on the model and equipment and may therefore differ. You will receive binding information when ordering or in the offer.

You will find further equipment options under the menu items Tetra equipment (if available), Special equipment and Individualization.

Data sheet

Drive type Hand crank with Chain drive
Gears / pinion 9-speed derailleur with 44/32/14 Chainring
Wheel size 26 inch on the impeller and 20 inch High-pressure tyres on the rear tyre
Break Disc brake and V-break Stricker handbikes and power assist devices are always equipped with double mechanical brakes such as coaster brake, V-brake and disc brake. If there is only one type of brake, it is double equipped, e.g. with two brake calipers on one disc brake or one disc brake and one V-brake. In addition, at least one of the existing brakes can be locked in order to park the handbike or power assist device. This ensures full safety.
Total weight From 18 kg
Max. user weight Standard load up to 120 kg user load. More than 120 kg is possible on request.

Equipment

Drive

Illustration can deviate.

Hand crank

The ergonomically mounted crank handle provides the drive.The handle lies comfortably in the hand, so that a longer distance can be covered without cramps in the palm of the hand.

Illustration can deviate.

Chain drive

The chain drive is the most common drive method for pedelecs. It consists of at least one chainring on the crank and a rear derailleur on the wheel, which are connected via the chain.

Illustration can deviate.

Ergonomic handles stemless with twist shifter

The comfortable ergo grips are cleverly mounted so that the centre of gravity is central to the axis of the hand crank. The gearshift device is a twist grip gearshift and is located on the handle.

Illustration can deviate.

Disc brakes

The braking power of the disc brakes is significantly stronger due to the higher surface pressure compared to the V-brake.

Illustration can deviate.

A

V-break

The V-brake is a simple and straightforward brake that is very accessible.

Electornic

Illustration can deviate.

Bike computer

The bike computer displays various information on a black and white display. The following information is displayed on it: current, maximum and average speed, riding distance, riding time and total kilometers.

Frame

Illustration can deviate.

Lupo frame

The light, robust aluminium frame in combination with the sophisticated aluminium milled parts that hold the assemblies together allow intensive off-road use and can be disassembled into two separate parts for transport in no time at all.

Impeller

Illustration can deviate.

26 inch wheel

With 26 inches, most obstacles are overcome without problems.

Colors

Illustration can deviate.

Metallic silver

The metallic silver shade has a special, robust shine. The subtle color submits to any environment and thus stands out little.

Special equipment

Stricker handbikes and power assist devices are adaptable to a wide variety of needs through our large range of equipment options and accessories. On this page you will get a small overview of common equipment options of this model range.

Further equipment options and additional accessories matching the model series can be found in the respective offer form.

Common options

Illustration can deviate.

Lipo-Drive

The lipo drive is a reliable and, above all, powerful drive which is realised via a wheel hub motor and a sophisticated control system.

Illustration can deviate.

Neodrive drive system

The Neodrive drive system from Alber is a dynamic drive that feeds energy into the wheel hub motor via the force ratio of the crank.

Tetra equipment

In this equipment form, our products meet the high requirements of tetraplegia without compressing safety aspects. Further information can be found under the menu item Tetra equipment.

Individualization

Stricker handbikes and traction devices can be customized. In addition to obvious customization options such as the seat width and the resulting frame size, there are also other ways to personalize the companion. On this page you will get an impression about the individualization possibilities of the product.

Available colors and coatings can be found on the colors and coatings page. All RAL special colours are available at an extra charge.

Colors

Illustration can deviate.

Frame colour

The frame on the Lupo can be completely coloured in all colours.

Documents

Are you looking for the right documents? We have collected a suitable selection of documents and information under the following links.

General Downloads under downloads.

Unpacking and installation guide under Help & Media.

Certificates under About us.

If you need further documents, we will be happy to help you personally. You can reach us via the contact form or by phone during our opening hours.

Documents for dealers

For dealers and distributors, our images are also available in full size and high resolution for all purposes. Whether on the web or as a print template. Contact us directly to get access to records, pictures, documents and more. We look forward to receiving your request.
